FBSA205/QFC軸承
SKF磐固晟是SKF進口軸承經銷 商，不僅為工業配套用戶提供SKF FBSA205/QFC軸承，在維修市場也提供足夠的支持，是SKF軸承在國內的優質經銷商之一，購買SKF FBSA205/QFC軸承，磐固晟是您放心的選擇。
型號：FBSA205/QFC
品牌：SKF
內徑：25
外徑：80
厚度：82
系列：角接觸推力球軸承 for screw drives, cartridge units with flanged housing
【更新日期：2016/8/3 電腦版 FBSA205/QFC軸承】
FBSA205/QFC軸承
| 角接觸推力球軸承 for screw drives, cartridge units with flanged housing | |||||||||||
| 公差, inner rings, outer rings, see also text | |||||||||||
| Preload, see specific bearing, see also text | |||||||||||
| Shaft fits, housing fits | |||||||||||
| 軸和軸承座公差 | |||||||||||
|
|||||||||||
| 主要數據尺寸 | 基本負荷額定值 | 疲勞負荷限值 | 可達到的速度 | 體積 | 型號 | ||||||
| 動態 | 靜態 | 預壓 | SKF | SNFA | |||||||
| A | B | ||||||||||
| d | D2 | A | C | C0 | Pu | ||||||
|
|
|||||||||||
| mm | kN | kN | r/min | kg | - | ||||||
|
|
|||||||||||
| 25 | 80 | 82 | 36,512 | 104 | 3,86 | 4500 | 2250 | 3,5 | FBSA 205/ QFC | BSQU 225 TFT | |
